[예매] CRANKSET CRS-X - GRAVEL / TRAIL

CRANKSET CRS-X - GRAVEL / TRAIL

X FOR CROSS COUNTRY

현대적인 XC 바이크를 위한 새로운 알로이 크랭크로 R2 타이프의 자매품이라고 할 수 있다. 최대한 가볍고 심플하게 디자인된 제품으로 형태와 FEM의 수 개월의 세부변경과정이후 이러한 극단적으로 깔끔하고 확실한 구조를 하진 디자인에 이르렀다: 2개의 양쪽 drilled “tubes” 그리고 완벽한 강성/무게 비율을 가진 machined matrix를 가진 aluminum cnc’d crankset의 조합이 그것이다. 어떠한 Ingrid chaingring과 spindle과도 호환된다.

SPECIFICATIONS:

• 소재: 2024 알루미늄 합금 (hollowed cranks) / 7075 알루미늄 합금 (spindle)

                 2024 alloy: 항공우주산업에서 주로 사용되는 무게 대비 강성이 가장 높은 알루미늄 합금

                 7075 alloy: 뛰어난 연성, 높은 강성, 높은 피로 저항성을 가진 알루미늄 합금

• 무게: 462g (M crank with L131 spindle, chainring 미포함)
• 길이: Small / Medium (170mm) / Large
• 스핀들 지름: 30mm for BSA, PF92, BB30
• K-Factor: 91.5mm (L131) / 96.5mm (L136) / 101.5 mm (with L141 spindle) (크랭크 외부 양측면 사이 폭)
• Q-Factor: 163mm (L131) / 168mm (L136) / 173 mm (with L141 spindle) (스페이서 등을 포함한 Bottom Bracket의 폭)
• Chain Line : 49.5mm (with spindle L131), 52mm (with spindle L136)
• Boost 호환
• 색상: Black, Titanium, Raw(no finish), Special Colours (Red, Orange, Yellow, Blue, Green, Violet)
• [주의] Ingrid chainring 미포함

COMPATIBILITY:

Ingrid 모든 chainrings과 spindles 호환

타 브랜드 체인링의 경우 Ingrid Spider를 같이 사용하고 110 x 5 BCD에 맞는 경우만 사용 가능

타 브랜드 스핀들은 호환 안됨

RELATED PRODUCTS: 로드 크랭크세트와 함께 사용가능한 Ingrid 제품

• Ingrid MTN/Gravel Single Chainrings (Direct Mount / 32T, 34T, 36T, 38T, 40T, 42T)
• Ingrid Road/Gravel Spider (110 X 5 BCD Single and Double Chainrings)
• Ingrid Cassettes (12 Speed 10-48T, 11 Speed 10-46T)
• Ingrid MTN Derailleur (12 Speed: RD1-M12S)

CRANKSET LOCK RING TOOL

• Ingrid 체인링 락링 체결을 위한 전용 tool 필요
• Crankset과 함께 구매할 경우 특별 번들 가격 제공

원산지: 100% MADE IN ITALY

CRANKSET CRS-X - GRAVEL / TRAIL

X for cross country.

This is the new alloy crankset in our way for the modern xc bikes.Sister of the R2 type, it is born to have lightness (as much as it’s possible) and simplicityAfter some month of iteration between shapes and FEM, we reached this new “radical as clean” and definitive structure for this new crankset: 2 drilled “tubes” at sides and a machined matrix for a perfect stifness/weight ratio in aluminum cnc’d cranksets.Compatible with any of our chainrings and spindles

SPECIFICATIONS:

• Material: 2024 almuminium alloy (cranks) / 7075 aluminium alloy (spindle)

                         2024 alloy is for aerospace industry and has a high strength to weight ratio

                         7075 alloy has good ductility, high strength, toughness, resistance to fatigue

• Weight: 462g (M cranks L131 spindle without chainring)
• Cranks Length: Small / Medium (170mm) / Large
• Spindle: 30mm that fits BSA, PF92, BB30
• K-Factor: 91.5mm (L131) / 96.5mm (L136) / 101.5 mm (with L141 spindle) (The width between cranks)
• Q-Factor: 163mm (L131) / 168mm (L136) / 173 mm (with L141 spindle) (The length of BB including spacers)
• Chain Line : 49.5mm (with spindle L131), 52mm (with spindle L136)
• Boost Compatible
• Colors: Black, Titanium, Raw(no finish), Special Colours (Red, Orange, Yellow, Blue, Green, Violet)
• Not Including a chainring

COMPATIBILITY:

Compatible with any of Ingrid chainrings and spindles

RELATED PRODUCTS:

• Ingrid MTN/Gravel Single Chainrings (Direct Mount / 32T, 34T, 36T, 38T, 40T, 42T)
• Ingrid Road/Gravel Spider (110 X 5 BCD Single and Double Chainrings)
• Ingrid Cassettes (12 Speed 10-48T, 11 Speed 10-46T)
• Ingrid MTN Derailleur (12 Speed: RD1-M12S)

CRANKSET LOCK RING TOOL

• Special tool useful for assembly the chainring lock ring
• Special price for bundle

100% MADE IN ITALY
