NICH LEGEND4 FRAME KITS
Solid All-Round Road Frame Kit with Max Tire Width 32mm
LONG-TERM REVIEW
January 17, 2023 I Nich Legend4 and Atem4s wheelset by Shane Goodhew (Australian)
"당신이 단단하고 아름답고 일체화된 느낌을 주는 올라운더(all-rounder)를 찾고 있는데 많은 지출은 하고 싶지 않은경우 나는 추천하고 싶다. 이 자전거는 자전거를 시작한 이래로 가장 즐겁게 타고 있는 자전거이다."
Nich Cycling Legedn4를 약 16,000km를 주행했기에 깊이있는 장기 리뷰를 올려보도록 한다.
- 주행감각(Feel): 첫번째 느낀 점은 다운힐할 때 핸들링 감각이였다. 과거에 탔었던 유명 브랜드의 자전거들보다 훨씬 안정감이 느껴졌고 다른 라이더들도 같은 이야기를 했다. 매우 강성(stiffness)이 높은 로드 자전거로 상대적으로 많은 량의 주행(일주일에 500~600km)했음에도 그 강성이 사라지지않았다.
- 공기역학(Aerodynamics): Nich Legend 4는 공기역학과 경량성의 균형을 찾으려는 시도가 녹아있는 자전거로 개인적으로 업힐에서 최고의 기록들을 세웠었고 평지에서 매우 빠른 속도로 달려본 결과 매우 휼륭한 공기역학 성능을 가지고 있음을 확인할 수 있었다. 특히 통합형 핸들바 시스템 (integrated handlebar system)으로 보기에 좋을 뿐 아니라 공기역학 성능이 배가되었다고 생각된다. Nich Atem4 60mm wheel을 대부분 시간에 사용했는데 평지에서의 속도에 향상이 있었다.
- 외관(Look): Nich Legend4는 분명 아름다운 자전거이다. 하지만 개인적으로 Nich에서 제공하는 것중 가장 좋아하는 것은 각 고객이 원하는 커스텀 페인팅을 제공해준다는 것이다. 나는 skywalker blue를 타고 있지만 다른 미친 수준의 색상들을 가진 Legend4가 생산되는 것을 보면서 다른 색상도 구매하고 싶은 충동을 느낄 정도였다.
- 고객 서비스 (Customer Service): 자전거는 당연히 사용함에 따라 닳거나 교체가 필요하게 된다. 개인적으로 우기가 지난 후 헤드셋 베어링을 교체하기 위해서 Nich에 연락을 하였는데 자전거 라이더들이 운영하는 작은 회사임에도 불구하고 그들은 자신들의 제품들에 대해 매우 열정적이였고 라이더들이 문제해결을 원하는 만큼 그들도 이슈 해결을 하려고 했고 응답도 매우 즉각적이고 해결책도 매우 빠르게 제공되었는데 이러한 고객 서비스는 자전거 업계에서 그렇게 흔하지는 않다.
PRODUCTION FEATURES
- Production I 각각의 NICH 제품은 고객에게 배송되기 전에 광범위한 디자인과 테스트 과정들을 통과한다. Nich의 우선순위는 제품의 성능과 안전성이다. 디자인으로 시작하여 몰딩(moulding)과 연구실 테스트(lab test)을 통해 장비들이 업계 스탠다드를 확실하게 충족하거나 넘어설 수 있도록 진행한다. 프로토 타입을 완성한 후 내부적으로 테스트하고 또한 샘플들을 사이클 프로팀에 보내 실제 필드 테스트를 통해 피드백을 받는다. 테스트 결과를 바탕으로 만족할 때까지 지속적으로 세부 스펙을 조정한다. 이러한 과정을 마친 후 제품은 생산에 들어가 판매용으로 나오게 된다.
- Carbon Fiber I 대만에 소재한 파트너 공장은 고품질의 Mitsubishi carbon fibre sheet를 사용하며 자전거와 휠의 특정부위들을 위한 적합한 카본 종류(carbon modulus)를 선택하여 적용한다. 높은 강직성(stiffness)과 반응성(responsiveness)을 요구하는 부위에는 high-modulus fibre를 사용하고 강성(strength)이 필요한 부위는 강한 카본 섬유로 추가로 보강하게 된다. 이로 인하여 자전거와 휠의 성능과 내구성의 최상의 균형을 얻을 수 있다. 이중 몰딩 기술(Double-Moulding technology)이 적용하여 카본 튜브 내부에 불필요한 카본 잉여를 줄인다. 이 과정을 통해 정확한 조정과 최적화가 가능하여 카본 잉여를 줄여 불필요한 무게 증가와 약한 연결부위들을 방지할 수 있다.
- Handpaint I 모든 최고급 카본 자전거는 Nich Bangkok workshop에서 수작업으로 페인팅된다. Nich Cycling은 단순한 레이싱 머신을 넘어서는 자전거를 제작하기를 원하기에 페인터들의 예술적 감각과 비전이 NICH carbon frame에 적용되도록 한다.
PRODUCT FEATURES
- 탁월한 핸들링 조정성: 고속 다운힐에서 안정적인 핸들링 조절이 가능하며 커브에서 인상적인 안정성 실현한다.
- 탁월한 항속성과 가속성: 너무 무겁지도 너무 가볍지도 않은 약 900그램의 프레임 무게로 고속 항속을 유지해야 할 때나 급격한 가속을 해야할 때 등 어떠한 상황에서도 적합한 프레임이다.
- 비포장 주행가능성: 32mm까지 타이어 장착이 가능하여 포장도로 레이싱뿐 아니라 semi-gravel routes에서도 라이딩이 가능하다.
SPECIFICATIONS
- 프레임 소재: Hi-Modulus Carbon Toray 800
- 포크 소재: Full Carbon Toray 800
- 케이블 시스템: Internal Cable & Di2 (Disc Brake Only)
- 시트포스트: Carbon Setback 15mm
- 핸들바 세트: Carbon Integrated Stem (Check its options)
- 헤드셋: FSA (1-1/8" to 1-1/4")
- 드레일러: Aluminum Plug-in
- 바텀 블라켓: Pressfit 86 Carbon
- 프레임 무게: 860 Gram (S Size)
- 포크 무게: 420 Gram (uncut)
- 핸들바 무게: 370 Gram (stem + Hand Integrated)
- 시트포스트 무게: 160 Gram (including clamp-lock)
- 장착 가능한 최대 타이어 두께: 32mm
FRAME GEOMETRY (Unit: mm)
FRAME SIZE |
XXS |
XS |
S |
M |
L |
XL |
Rider Hight (cm) |
155-166 |
165-175 |
170-180 |
175-185 |
180-190 |
185-195 |
ST Length (A) |
430 |
460 |
490 |
520 |
550 |
580 |
ETT Length(B) |
505 |
520 |
535 |
550 |
570 |
590 |
HT Length(C) |
102 |
112 |
127 |
147 |
167 |
192 |
Chain Stay(D) |
408 |
408 |
408 |
408 |
408 |
408 |
HT Angle(E) |
70.8 |
71.4 |
72 |
73 |
73 |
73 |
ST Angle(F) |
75 |
74.5 |
74 |
73.5 |
73 |
72.5 |
BB Drop(G) |
71 |
71 |
71 |
70 |
70 |
70 |
Front Center(H) |
571 |
576 |
583 |
588 |
601 |
615 |
Fork Length(I) |
370 |
370 |
370 |
370 |
370 |
370 |
Wheelbase(J) |
966 |
972 |
981 |
985 |
999 |
1012 |
Fork Offeset(K) |
45 |
45 |
45 |
45 |
45 |
45 |
Seat Setback |
15 |
15 |
15 |
15 |
15 |
15 |
Reach |
370 |
376 |
383 |
390 |
397 |
404 |
Stack |
500 |
512 |
530 |
549 |
571 |
595 |
![]()
INTEGRATED HANDLEBAR OPTIONS
![]()
THE CONTENTS
- Legend4 Frame
- Fork
- Seatpost
- Intergate Handlebar
- Headset
보증 기간: 3 YEARS (PROPER USE) / 1 YEAR FOR PAINTWORK
원산지: DESIGNED IN THILAND / MADE IN TAIWAN
NICH LEGEND4 FRAME KITS
Solid All-Round Road Frame Kit with Max Tire Width 32mm
LONG-TERM REVIEW
January 17, 2023 I Nich Legend4 and Atem4s wheelset by Shane Goodhew (Australian)
So I’ve now ridden around 16,000 k’s on my Nich Cycling Legend4, so I guess I can give a bit of a long term in depth review, right?
I’d recommend it if you’re looking for a solid all rounder that looks and feels the part but you don’t want to spend a tonne of cash. It’s the bike I’ve most enjoyed since I started riding.
- Feel: The first thing I noticed about this bike was the handling when going downhill, it felt much more secure than previous big brand bikes that I have ridden, and other riders have said the same thing. It’s a very stiff road bike that hasn’t lost much stiffness even with a relatively large amount of riding done (roughly 500-600km a week since I got it).
- Aerodynamics: The Legend 4 fits well in this new hybrid style of bikes that tries to find the balance of aero and lightweight disc (think SL7, TCR etc) and I think it fits this bill very well. I’ve done some of my best times up good climbs with this bike, and I’ve also ridden very fast on flat roads and found it to be nice and aero. The aerodynamics is doubled down with the integrated handlebar system that you get when purchasing the bike. Having a one piece integrated system not only looks very nice but does add to the aerodynamics of the bike.
- I’ve also been using Nich’s Atem 4 60mm wheels for most of my riding which has added to the speed on flat and rolling roads.
- Look: obviously it’s a beautiful bike. But what I like most about what Nich is offering is that each bike colourway is absolutely customisable for each individual. I got the skywalker blue, but I’ve seen some absolute bangers come out of the factory recently with some insane colourways that made me want another one.
- Customer Service (very important): due to the nature of cycling, things are always going to end up wearing down or needing a replacement. I recently replaced the bearings in my headset after wet season and I contacted Nich to help me with the size etc. Nich cycling isn’t a major corporation, it’s a business run by riders for riders, and they are very passionate about their products. If there’s an issue they want to solve it with as much resolve as the rider does. Response is pretty much instant and the solutions are available very quickly which is not always the case in this industry.
PRODUCTION FEATURES
- Production I Every single NICH product, be it carbon or aluminium wheel or frame, undergoes extensive design and testing procedures before it’s ready to be shipped to our customers. Our priorities are performance and the safety of our products. We start by drafting and drawing, then moulding and lab testing to make sure the equipment meets or exceeds the industry standard. After we perfect a prototype, we test the equipment internally as well as sending samples for our pro-team to field-test and provide feedback. We then continually adjust the specs from the feedback we have until we are satisfied. Only then when our products will be ready for production and general purchase.
- Carbon Fiber I Our partner factory utilises high quality Mitsubishi carbon fibre sheets and we select appropriate modulus for the specific parts of bikes and wheels. We use high-modulus fibre for the areas that require stiffness and responsiveness, whilst reinforcing them with strong fibre in the areas that require strength. This gives us the best possible balance for performance and durability in all of our carbon frames and wheels. We also use special resin for wheels’ sidewall to withstand heat buildup from excessive braking. The Double-Moulding technology we use reduces fibre excess inside the carbon tube. This process gives us accurate control and optimisation, reducing excess materials that might result in unwanted weight and weak joints. For our aluminium product, we use CNC technology for the best use of material and balance between weight, aesthetic, and performance.
- Handpaint I All of our top-end carbon bikes are hand-painted in the Nich Bangkok workshop. Here at Nich Cycling we want your bike to be more than just a racing machine and therefore we impart our painter’s artistic style and vision on every NICH carbon frame.
PRODUCT FEATURES
- Great Maneuvability: Very well controllable when going downhill with hightspeed and impressive curve turning
- All-Rounder: Not too heavy and Not too light. About 900 grams for frame weight, which makes the bike can fit with allround situation (Hold on high speed, Accelerate for sprinter)
- Semi-Gravel: Max tire width (up to 32mm) which means you can ride on semi-gravel routes.
SPECIFICATIONS
- Frame Material: Hi-Modulus Carbon Toray 800
- Fork: Full Carbon Toray 800
- System: Internal Cable & Di2 (Disc Brake Only)
- Seatpost: Carbon Setback 15mm
- Handset: Carbon Integrated Stem (Check its options)
- Headset: FSA (1-1/8" to 1-1/4")
- Derailleur: Aluminum Plug-in
- Bottom Bracket: Pressfit 86 Carbon
- Frame Weight: 860 Gram (S Size)
- Fork Weight: 420 Gram (uncut)
- Handlebar Weight: 370 Gram (stem + Hand Integrated)
- Seatpost Weight: 160 Gram (including clamp-lock)
- Max Tyre Width: 32mm
FRAME GEOMETRY (Unit: mm)
FRAME SIZE |
XXS |
XS |
S |
M |
L |
XL |
Rider Hight (cm) |
155-166 |
165-175 |
170-180 |
175-185 |
180-190 |
185-195 |
ST Length (A) |
430 |
460 |
490 |
520 |
550 |
580 |
ETT Length(B) |
505 |
520 |
535 |
550 |
570 |
590 |
HT Length(C) |
102 |
112 |
127 |
147 |
167 |
192 |
Chain Stay(D) |
408 |
408 |
408 |
408 |
408 |
408 |
HT Angle(E) |
70.8 |
71.4 |
72 |
73 |
73 |
73 |
ST Angle(F) |
75 |
74.5 |
74 |
73.5 |
73 |
72.5 |
BB Drop(G) |
71 |
71 |
71 |
70 |
70 |
70 |
Front Center(H) |
571 |
576 |
583 |
588 |
601 |
615 |
Fork Length(I) |
370 |
370 |
370 |
370 |
370 |
370 |
Wheelbase(J) |
966 |
972 |
981 |
985 |
999 |
1012 |
Fork Offeset(K) |
45 |
45 |
45 |
45 |
45 |
45 |
Seat Setback |
15 |
15 |
15 |
15 |
15 |
15 |
Reach |
370 |
376 |
383 |
390 |
397 |
404 |
Stack |
500 |
512 |
530 |
549 |
571 |
595 |
![]()
INTEGRATED HANDLEBAR OPTIONS
![]()
THE CONTENTS
- Legend4 Frame
- Fork
- Seatpost
- Intergate Handlebar
- Headset
WARRANTY: 3 YEARS (PROPER USE) / 1 YEAR FOR PAINTWORK
DESIGNED IN THILAND / MADE IN TAIWAN
